FOR MILES OF SMILES

WE MADE OUR TOURING HYBRID TO BE VERSATILE, EASY TO LIVE WITH AND COMFORTABLE. THE POWERFUL BOSCH PERFORMANCE MOTOR WITH BOSCH SMART SYSTEM AND POWERTUBE BATTERY ARE ALL SO NEATLY INTEGRATED INTO THE DESIGN, YOU'LL BARELY NOTICE THEY'RE THERE – APART FROM THE EXTRA HELP AT THE PEDALS, OF COURSE. REVISED EFFICIENT COMFORT GEOMETRY CENTRES AROUND A 63MM TRAVEL SUSPENSION FORK FOR COMFORT AND CONTROL, EVEN ON ROUGH ROADS. THE CARRIER IS DESIGNED TO MAKE CARRYING A LOAD EASIER, AND THE SEAT CLAMP EVEN HAS A HIDDEN TOOL IN ITS LEVER. ADD THE NEW ACID CHAIN GUARD, KICKSTAND AND FULL-LENGTH MUDGUARDS AND YOU'VE GOT EVERYTHING YOU NEED. AND, WITH A CHOICE OF CLASSIC MEN'S, TRAPEZE OR EASY ENTRY FRAME DESIGNS, THERE'LL BE A STYLE AND SIZE THAT'S PERFECT FOR YOU.

• FRAME MATERIAL ALUMINIUM SUPERLITE
• BATTERY 500 WH

ONE BIKE, MANY REASONS: THE TOURING HYBRID ONE'S WIDE CHOICE OF FRAME STYLES AND SIZES MEANS THERE'S ONE THAT'S TAILOR-MADE JUST FOR YOU. WITH COMFORTABLE HANDLING, A POWERFUL BOSCH PERFORMANCE DRIVE AND A FULL COMPLEMENT OF PRACTICAL ACCESSORIES, IT'S THE BIKE THAT'LL SLOT RIGHT INTO YOUR BUSY LIFE.

FRAME

• FRAME ALUMINIUM SUPERLITE, GRAVITY CASTING TECHNOLOGY, EFFICIENT COMFORT GEOMETRY, FULL INTEGRATED BATTERY, 1.5 HEADTUBE, SEMI INTEGRATED CARRIER
• SIZE MEN: S (50CM), M (54CM), L (58CM), XL (62CM); TRAPEZE: XS (46CM), S (50CM), M (54CM); EASY ENTRY: XS (46CM), S (50CM), M (54CM), L (58CM)

SUSPENSION

• SUSPENSION FORK SR SUNTOUR NVX30 COIL, 63MM

E-BIKE SYSTEM

• DRIVE UNIT BOSCH DRIVE UNIT PERFORMANCE GENERATION 3 (75NM) CRUISE (250WATT), SMART SYSTEM
• BATTERY BOSCH POWERTUBE 500
• REMOTE BOSCH LED REMOTE
• CHARGER BOSCH 4A

DRIVETRAIN & BRAKES

• BRAKE SYSTEM SHIMANO BR-MT200, HYDR. DISC BRAKE (180/180)
• REAR DERAILLEUR SHIMANO RD-M3100-SGS, 9-SPEED
• SHIFTERS SHIMANO SL-M3100-R, RAPIDFIRE-PLUS
• CRANKSET ACID E-CRANK, 40T, 170MM
• CASSETTE SHIMANO CS-HG201, 11-36T
• CHAIN KMC X9

COCKPIT

• HANDLEBAR CUBE COMFORT TRAIL BAR, 700MM
• STEM CUBE PERFORMANCE STEM PRO, 31.8MM
• GRIPS ACID TRAVEL COMFORT
• HEADSET ACROS AZF-1031, TOP ZERO-STACK 1 1/2" (ZS 56MM), BOTTOM ZERO-STACK 1 1/2" (ZS 56MM)

WHEELS

• FRONT HUB SHIMANO HB-TX505, QR, CENTERLOCK
• REAR HUB SHIMANO FH-TX505, QR, CENTERLOCK
• RIMS RODI BLACKROCK 23, 36H, DISC, TUBELESS READY
• TYRES SCHWALBE BIG BEN, ACTIVE, K-GUARD, 55-622

FINISHING KIT

• SEAT POST CUBE PERFORMANCE POST, 30.9MM
• SADDLE NATURAL FIT SEQUENCE COMFORT
• PEDALS ACID PP TREKKING
• FRONT LIGHT CUBE SHINY 50 LUX, 12V, DC
• REAR LIGHT ACID MUDGUARD REAR LIGHT PRO-E, 12V, DC
• KICKSTAND ACID FM PURE KICKSTAND
• MUDGUARDS ACID 65 BB-MOUNT
• BELL EASY BELL
• CARRIER ACID SEMI-INTEGRATED CARRIER, ACID RILINK ADAPTER COMPATIBLE

PRODUCT INFORMATION

• WEIGHT 25,7 KG
• COLOUR GREY´N´WHITE
