PICK YOUR LINE AND LET IT RIP. FROM CHUNKY ALPINE TERRAIN TO WARP-SPEED PARK RUNS, THIS HARD-CHARGING 29ER FEASTS ON RUGGED TERRAIN, GIVING YOU THE CONFIDENCE TO CHARGE HARDER.

KEY PERFORMANCE FACTORS

RACE-BRED SUSPENSION

MAESTRO REAR SUSPENSION AND A 170MM FORK DEVELOPED AND TESTED IN ENDURO WORLD SERIES RACES. THE TRUNNION MOUNT REAR SHOCK HAS A LONGER STROKE AND SMOOTHER FEEL, AND AN ADVANCED FORGED COMPOSITE UPPER ROCKER ARM ADDS STIFFNESS WHILE LOWERING OVERALL FRAME WEIGHT.

PROGRESSIVE ENDURO GEOMETRY

A STRONG AND DURABLE ALUUX SL ALUMINUM FRAMESET HELPS YOU RIDE AGGRESSIVE DESCENTS AND RAIL CORNERS WITH CONFIDENCE. ENDURO-OPTIMIZED HEAD AND SEATTUBE ANGLES, PLUS A 170MM FORK WITH 44MM OFFSET, PRODUCE CONFIDENT FRONT-END HANDLING.

29ER CONFIDENCE AND CONTROL

LARGER 29-INCH DIAMETER WHEELS ROLL OVER RUGGED ENDURO TERRAIN WITH IMPROVED BALANCE AND STABILITY, GIVING YOU THE MOMENTUM TO CRANK UP TOUGH CLIMBS AND THE CONFIDENCE TO FLY ON FAST, TECHNICAL DESCENTS.

SPECS

• SIZES - S, M, L COLOURSSTARRY NIGHT / JADE TEAL
• FRAME - ALUXX SL-GRADE ALUMINUM FRONT AND REAR TRIANGLES, 146MM MAESTRO SUSPENSION, 12X148MM THRU-AXLE
• FORK - FOX 36 PERFORMANCE ELITE, GRIP 2 DAMPER, 37MM OFFSET, 170MM, 15X110 KABOLT X, CUSTOM TUNED FOR GIANT
• SHOCK - FOX DHX2 PERFORMANCE ELITE, LOCKOUT, 205/60, CUSTOM TUNED FOR GIANT: S:400LB, M:400LB, L:450LB
• HANDLEBAR - GIANT CONTACT SL TR35, 800X35MM, 20MM RISE
• GRIPS - GIANT TACTAL PRO SINGLE S:120MM, M:120MM, L:130MM
• STEM - GIANT CONTACT SL 35 S:40MM, M:40MM, L:40MM
• SEATPOST - GIANT CONTACT SWITCH DROPPER, REMOTE S: 125MM TRAVEL / 30.9 X 395MM M: 150MM TRAVEL / 30.9 X 440MM L: 170MM TRAVEL / 30.9 X 450MM
• SADDLE - GIANT ROMERO
• PEDALS - NOT INCLUDED
• SHIFTERS - SRAM NX EAGLE, 1X12
• FRONT DERAILLEUR - N/A
• REAR DERAILLEUR - SRAM NX EAGLE
• BRAKES - SHIMANO SLX BR-M7120, HYDRAULIC, SHIMANO RT-66 ROTORS [F]203MM, [R]203MM
• BRAKE LEVERS - SHIMANO SLX BL-M7100
• CASSETTE - SRAM NX EAGLE, 11X50
• CHAIN - SRAM NX EAGLE
• CRANKSET - TRUVATIV DESCENDENT 6K, DUB, 32T S:165MM, M:170MM, L:170MM
• BOTTOM BRACKET - SRAM DUB, PRESS FIT
• RIMS - GIANT AM 29 SLEEVE-JOINT RIM, 30MM INNER WIDTH
• HUBS - GIANT BOOST, SEALED
• SPOKES - SAPIM
• TYRES - [F] MAXXIS ASSEGAI 29X2.5 WT, 3C MAXXTERRA, EXO+, TR [R] MAXXIS MINION DHR II 29X2.4 WT, 3C MAXXTERRA , EXO+, TR TUBELESS
• EXTRAS - FACTORY SET UP TUBELESS, 2.5" MAX TYRE SIZE, 36T MAX CHAINRING SIZE, MRP SXG CHAIN GUIDE
