RIDE ROADS, GRAVEL OR DIRT WITH THIS VERSATILE ALUMINUM ALL-ROUNDER. A COMPOSITE FORK GIVES IT A SMOOTH RIDE, AND A FLIP CHIP LETS YOU ADJUST WHEELBASE AND TIRE CLEARANCE.

KEY PERFORMANCE FACTORS

CONFIDENT HANDLING

FRAME IS DESIGNED WITH ENDURANCE POSITIONING AND SHORTER CHAINSTAYS FOR PRECISE HANDLING, AGILITY AND CONTROL. A LONGER REACH, SHORTER STEM AND LOWER BOTTOM BRACKET DROP IMPROVES STABILITY ON RUGGED TERRAIN.

TUNED COMPLIANCE

DROPPED SEATSTAYS WITH THIN TUBING ABSORB ROAD SHOCKS AND VIBRATIONS. THE D-FUSE HANDLEBAR AND SEATPOST WORK AS A SYSTEM TO ADD COMPLIANCE WITHOUT SACRIFICING STIFFNESS WHILE CORNERING, SPRINTING OR CLIMBING.

ADAPTABLE TO THE TERRAIN

A FLIP CHIP ON THE REAR DROPOUT ADJUSTS THE WHEELBASE: SHORT FOR QUICKER HANDLING AND ACCELERATION, OR LONG FOR IMPROVED STABILITY AT SPEED. THE LONG SETTING ALLOWS FOR LARGER DIAMETER TIRES UP TO 53MM. YOU CAN CHOOSE THE INCLUDED D-FUSE SEATPOST FOR MAXIMUM COMPLIANCE, OR SWITCH TO A 30.9MM ROUND OR DROPPER POST.

SPECIFICATIONS

• SIZES - S, M, M/L, L, XL
• COLOURS - ALPINE GREEN
• FRAME - ALUXX-GRADE ALUMINUM, 12X142MM THRU-AXLE, DISC, FLIP CHIP DROPOUT
• FORK - ADVANCED-GRADE COMPOSITE, FULL-COMPOSITE OVERDRIVE STEERER, 12MM THRU-AXLE, DISC
• HANDLEBAR - GIANT CONTACT XR D-FUSE, 31.8MM XS:42CM, S:42CM, M:44CM, M/L:44CM, L:46CM, XL:46CM
• STEM - GIANT CONTACT, 8-DEGREE XS:50MM, S:60MM, M:70MM, M/L:80MM, L:80MM, XL:90MM
• SEATPOST - GIANT D-FUSE, ALLOY, 14MM OFFSET
• SADDLE - GIANT GRIT
• PEDALS - PEDALS NOT SUPPLIED
• SHIFTERS - SHIMANO CUES U6030, 2X10
• FRONT DERAILLEUR - SHIMANO CUES U6030
• REAR DERAILLEUR - SHIMANO CUES U6020
• BRAKES - SHIMANO CUES U6030 HYDRAULIC, GIANT MPH ROTORS [F]160MM, [R]160MM
• BRAKE LEVERS - SHIMANO CUES U6030 HYDRAULIC
• CASSETTE - SHIMANO CS-LG300, 11X39
• CHAIN - KMC X11
• CRANKSET - SHIMANO FC-U6030-2, 32/46 XS:170MM, S:170MM, M:172.5MM, M/L:172.5MM, L:175MM, XL:175MM
• BOTTOM BRACKET - SHIMANO, THREADED
• RIMS - GIANT S-X2, ALLOY
• HUBS - GIANT ALLOY, 12MM THRU-AXLE
• SPOKES - STAINLESS
• TYRES - GIANT CROSSCUT AT 2, 700X38C, TUBELESS
• EXTRAS - TUBELESS PREPARED
• MAX TYRE CLEARANCE - 53MM MAX TYRE SIZE IN "LONG" FLIP CHIP POSITION, 45MM MAX TYRE SIZE IN "SHORT" FLIP CHIP POSITION WITH 1X DRIVETRAINS. MAX TYRE SIZE WITH A 2X DRIVETRAIN IS 45MM IN THE LONG POSITION.
