THE MOUNTAIN BIKE EXPERIENCE STARTS HERE. WITH A REDESIGNED FRAME THAT’S NOW LIGHTER AND MORE DURABLE, ALONG WITH A SMOOTH-RIDING SUSPENSION FORK, THRU-AXLE HUBS*, AND A 1X DRIVETRAIN*, THIS ALUMINIUM HARDTAIL IS EVERYTHING AN ASPIRING MTB RIDER NEEDS TO EVOLVE AND ADVANCE. *ON SELECT MODELS

HIGHLIGHTS

THE MOUNTAIN BIKE EXPERIENCE STARTS HERE. WITH A REDESIGNED FRAME THAT’S NOW LIGHTER AND MORE DURABLE, ALONG WITH A SMOOTH-RIDING SUSPENSION FORK, THRU-AXLE HUBS*, AND A 1X DRIVETRAIN*, THIS ALUMINIUM HARDTAIL IS EVERYTHING AN ASPIRING MTB RIDER NEEDS TO EVOLVE AND ADVANCE.

KEY PERFORMANCE FACTORS

MODERN MTB DESIGN TAPERED FORK STEERER TUBES*, QUALITY COMPONENTS INCLUDING A 1X DRIVETRAIN* WITH CLUTCH-EQUIPPED REAR DERAILLEURS, THRU-AXLE HUBS*, INTERNAL CABLE ROUTING (INCLUDING DROPPER SEATPOST) AND AN INTEGRATED CHAINSTAY PROTECTOR GIVE ASPIRING TRAIL RIDERS ROOM TO GROW. *ON SELECT MODELS

OFF-ROAD CONTROL NEW GEOMETRY IS OPTIMISED FOR CONFIDENT TRAIL RIDING AND TWO DIFFERENT WHEEL SIZES (27.5 OR 29-INCH) DEPENDING ON FRAME SIZE. THE GEOMETRY IS ALSO DESIGNED FOR FRONT SUSPENSION WITH EITHER AN 80MM OR 100MM FORK DEPENDING ON FRAME SIZE. ALL MODELS HAVE CLEARANCE FOR HIGH-VOLUME TYRES (UP TO 2.4-INCH) FOR TRACTION AND GRIP ON TECHNICAL TERRAIN.

LIGHT AND DURABLE ALL-NEW ALUXX ALUMINIUM FRAME FEATURES UPDATED SHAPING AND A LIGHTER OVERALL WEIGHT FOR IMPROVED PERFORMANCE ON OFF-ROAD TERRAIN.

SPECS

• SIZES 27.5: XS,S,M,L 29: S,M,L,XL,XXL
• COLOURS - GLOSS MARS DUST/BLACK/CHROME, GLOSS ULTRA NAVY/CHROME
• FRAME - ALUXX-GRADE ALUMINIUM, DISC
• FORKS - XC32-2 RCL, AIR SPRUNG, HYDRAULIC LOCKOUT, TAPERED ALUMINIUM STEERER, ALUMINIUM STANCHIONS, 15X110 THRU AXLE XS&S: 80MM TRAVEL (27.5) M-XXL:100MM TRAVEL (29)
• SHOCK - N/A
• HANDLEBAR - GIANT CONNECT TRAIL, 31.8MM XS&S: 690MM (27.5) M-XXL: 780MM (29)
• GRIPS - GIANT SOLE-O
• STEM - GIANT SPORT, 7-DEGREE RISE
• SEATPOST - GIANT CONTACT SWITCH CORE 2 POSITION DROPPER POST, 30.9MM XS&S: 100MM DROP X 350MM (27.5) M-XXL: 120MM DROP X 400MM (29)
• SADDLE - GIANT ERGOCONTACT TRAIL
• PEDALS - MTB CAGED
• SHIFTERS - SHIMANO DEORE M6100, 1X12
• FRONT DERAILLEUR - N/A
• REAR DERAILLEUR - SHIMANO DEORE M6100
• BRAKES - SHIMANO DEORE BR-MT200, HYDRAULIC, SHIMANO RT-10 ROTORS [F]180MM, [R]160MM
• BRAKE LEVERS - SHIMANO DEORE BL-MT200
• CASSETTE - SHIMANO DEORE M6100, 10X51
• CHAIN - KMC X12
• CRANKSET - PROWHEEL MPX, 32T (27.5) OR 30T (29)
• BOTTOM BRACKET - CARTRIDGE
• RIMS - GIANT GX03V 29 OR 27.5, ALLOY, DOUBLE WALL, 21MM INNER WIDTH
• HUBS - SHIMANO, SEALED BEARING, [F] 15X110 THRU AXLE, [R] 12X142 THRU-AXLE
• SPOKES - STAINLESS, 14G
• TYRES - MAXXIS REKON 27.5X2.4" OR MAXXIS REKON RACE 29X2.4", WIRE BEAD
• EXTRAS-
• MAX TYRE CLEARANCE - 2.4"
