THE TRAIL IS CALLING, AND HERE’S YOUR ANSWER. THIS BALANCED, SMOOTH-RIDING E-BIKE GIVES YOU A SMOOTH BOOST OF POWER AND TOTAL CONTROL, SO YOU CAN HAVE MORE FUN AND EXPAND YOUR OFF-ROAD RIDING CAPABILITIES.

KEY PERFORMANCE FACTORS

SMOOTH POWER DELIVERY THE SYNCDRIVE CORE MOTOR TECHNOLOGY DELIVERS SMOOTH, INSTANTANEOUS POWER TO CONQUER ALL KINDS OF TERRAIN AND HAVE MORE FUN.

BALANCED, CONFIDENT HANDLING LIGHTWEIGHT ALUMINUM FRAME WITH TRAIL-FRIENDLY GEOMETRY, 100MM OF FRONT SUSPENSION TRAVEL, AND FAST ROLLING 27.5-INCH OR STABLE 29-INCH WHEELS WITH TUBELESS TYRES PUTS YOU IN CONTROL ON OFF-ROAD TERRAIN.

LONG-LASTING BATTERY SIDE RELEASE ENERGYPAK WITH 500WH OF CAPACITY IS EASY TO CHARGE WITH OUR 4A SMART CHARGER.

RANGE

HOW FAR CAN I EXPECT TO RIDE ON A SINGLE BATTERY CHARGE?

THE RANGE FOR A SINGLE BATTERY CHARGE CAN VARY GREATLY DEPENDING ON CONDITIONS SUCH AS THE COMBINED WEIGHT OF THE RIDER AND CARGO; WIND RESISTANCE; TYRE PRESSURE AND TREAD PROFILE; TERRAIN AND ELEVATION CHANGES; ROAD OR TRAIL SURFACE; OUTDOOR TEMPERATURE; MAINTENANCE OF THE E-BIKE; AND THE CONDITION OF THE BATTERY.

THE BAR BELOW GIVES AN APPROXIMATE RANGE. CONDITIONS ARE CATEGORIZED AS EXTREME, GOOD AND IDEAL. EXTREME CONDITIONS TYPICALLY OCCUR WHEN RIDING WITH A HEAVY LOAD, STRONG HEADWINDS OR EXCESSIVE CLIMBS.

ENERGYPAK 500 / SYNCDRIVE SPORT

RANGE

• EXTREME: 34 MILES
• GOOD: 68 MILES
• IDEAL: 111 MILES

SPECS

• MOTOR - SYNCDRIVE SPORT, 70NM, POWERED BY YAMAHA
• CONTROLLER - RIDECONTROL ONE
• BATTERY - ENERGYPAK 500WH
• CHARGER - ENERGYPAK 4A FAST CHARGER
• SIZES - S, M, L, XL
• COLOURS - MATT GRAPHITE
• FRAME - ALUXX ALUMINUM, OVERDRIVE 1½ - 1⅛" HEAD TUBE, INTEGRATED KS18 KICKSTAND MOUNT
• FORK - SR SUNTOUR XCM ATB COIL 29" 100MM TRAVEL, TAPERED 1½ - 1⅛" STEERER
• HANDLEBAR - GIANT CONNECT TR RISER 31.8X690~750MM
• GRIPS - GIANT SOLE-O GRIP
• STEM - GIANT CONTACT
• SEATPOST - GIANT 30.9MM, 2-BOLT MICRO ADJUSTABLE, FORGED ALUMINIUM
• SADDLE - GIANT SPORT
• PEDALS - ALUMINUM PLATFORM
• SHIFTERS - SHIMANO ALTUS 1X9 SPEED
• REAR DERAILLEUR - SHIMANO ALIVIO
• BRAKES - TEKTRO HD-M275, HYDRAULIC DISC, 160/180MM
• BRAKE LEVERS - TEKTRO HD-M275
• CASSETTE - SHIMANO CS-HG200, 11-36T, 9-SPEED
• CHAIN - KMC E.9 SPORT, E-BIKE OPTIMIZED
• CRANKSET - FSA COMET E-BIKE CRANK ARM SET FSA MEGATOOTH DIRECT-MOUNT 1X STEEL 36T
• BOTTOM BRACKET - N/A
• RIMS - GIANT GX03V
• HUBS - GIANT ETRACKER SPORT, [F] 9MM QR [R] 135MM QR
• SPOKES - STAINLESS STEEL
• TYRES - KENDA BOOSTER 27.5X2.2", WIRE BEAD
